Gaskets Enveloped with PTFE are designed to address the growing problem of sealing in the most hostile chemical and temperature environments. National Unispares Group PERG combines the best qualities of two materials, PTFE on the outside with its chemical inertness and an elastomeric on the inside for resilience. This unique combination forms a highly effective, long lasting seal for the most demanding applications.PERG 850 Gaskets are available in over 60 standard crosssection sizes from 50 sq.mm to 1500 sq.mm. Standard PERG Gaskets are comprised of PTFE over Engineered Rubber Insert, and can be used in temperatures from -60° to +260°C depending upon the choice of elastomeric core.Encapsulated Gaskets are primarily used as a static seal(axial or radial).
1.Encapsulation material: PTFE (Poly Tetra FluoroEthylene)
2. Core material: Rubber Insert (FG/FDA – German Make)
3. Continuous service temperature:
A. PTFE Encap with FG Eng Rubber Core: 260C to -60C
B. PTFE Encap with Viton® Core: 260C to -23C
4. Coefficient of friction: .1 to .2 on metal surfaces.
5. Water absorption: <0.01.
6. Average total shore A hardness: 75-80 shore A for
Engineered Rubber core.
7. FDA Compliance: The TEFLON® PTFE encapsulation of
the Gasket complies with part 177 of Title 21 of the Food
and Drug Administration’s regulations for safe use as articles
or components of articles for producing, manufacturing,
processing, preparing, treating, packing, transporting or
holding food in accordance with regulation 177.1550.
| National Unispares Group – PERG ® | Regular PTFE NA Gasket |
|---|---|
| PERG-Food Grade and complies to GMP and US FDA 21 CFR 177.2600/ 1550 Norms | Does not comply |
| Higher Sealing capacity because of the Elastomeric Filler (Silicone Rubber Filler) | Low Sealing capacity because of Rigid NA Filler (NA Filler |
| Longer Life as the Gasket is less Rigid and suitable for app | Reduced Life as the Gasket is Rigid |
| Greater Compressibility , Zero Leakage | Reduced Compressibility, Leakage occurs |
| Double/ Triple the life compared to NA Gasket | Frequent Damages leading to production loss |
| Higher Pressure and Temp withstanding capacity | Lower Pressure and Temp withstanding capacity |
| Higher Life to Cost Ratio | Lower Life to Cost Ratio |
| Mfg under Clean Room conditions/ Suitable to use in Clean Room | Not Mfg under Clean Room conditions/ Not suitable for Clean Room usage |
