Silicone Fluid Transfer
Tubing US2560

Peroxide-cured silicone with polyester braid reinforcement for high-pressure sterile transfer, -90°C to +220°C, 1/4in to 4in.

US2560 Silicone Pump Tubing’s

SiliPure US2560 Biopharma Tubing is a high-performance, biopharmaceutical-grade tubing made from platinum-cured silicone. Engineered to meet the stringent requirements of the biopharma industry, it offers excellent resistance to repeated autoclaving and minimizes the adhesion of blood products and other sanitary fluids. Available in sizes starting from 1/16″ ID and above, SiliPure US2560 features laser-marked part numbers and lot codes to ensure complete product traceability.

Salient Features

Two Hardness Options – 50 or 65 Shore A.
Ultra-Pure Silicone – Biopharma-grade for high purity and reliability.
Full Traceability – Laser-marked with part numbers and lot codes.
Smooth Inner Surface – Improves fluid flow and prevents particle buildup.
Wide Temperature Range – From -80°F (-62°C) to 500°F (260°C).
Tested for Safety – Extractables & leachables study done for compatibility.
Validation Support – Guide available for regulatory needs.
Bacteria Resistant – Sterilizable and non-reactive to body tissues.
No Plasticizers – Soft, flexible, and contamination-free.
Cleanroom Made – Class 10,000 environment for maximum cleanliness.
Precision Dimensions – Laser-checked for consistent sizing.
Biocompatible – Meets USP Class VI & ISO 10993 standards.
Color-Coded Option – Easy identification during use.
Batch Traceability – Permanent laser etching for every lot.

Application

Sterile Fill and Transfers
Drug Delivery
Media Processing
Cell Harvest
Upstream and Downstream Biopharma Applications
High Purity Water Transfer
Buffer and Media Preparation
Purification Operations
Diagnostics Products

Certifications

Full Specification Range

Product Number	ID		OD		Wall thickness		PUMP SIZE	STANDARD LENGTH feet (')
	mm	Inch(")	mm	Inch(")	mm	Inch(")
BN2560NF1905-2858	19.05	0.75"	28.58	1.125"	4.75	0.187"	#191	25'
BN2560NF1905-3175	19.05	0.75"	31.75	1.25"	6.35	0.25"	#90	25'
BN2560NF2540-3493	25.4	1.0"	34.93	1.375"	4.75	0.187"	#92	25'
BN2560NF0157-0475	1.57	0.062"	4.75	0.187"	1.57	0.062"	#14	50'
BN2560NF0157-0635	1.57	0.062"	6.35	0.25"	0.79	0.031"	#119	50'
BN2560NF0318-0635	3.18	0.125"	6.35	0.25"	1.57	0.062"	#16	50'
BN2560NF0318-0792	3.18	0.125"	7.92	0.312"	2.36	0.093"	#03, #25	50'
BN2560NF0475-0335	4.75	0.187"	3.35	0.132"	1.57	0.062"	#25	50'
BN2560NF0475-0953	4.75	0.187"	9.53	0.375"	2.36	0.093"	#15	50'
BN2560NF0475-1110	4.75	0.187"	11.1	0.437"	3.18	0.125"	---	50'
BN2560NF0635-0953	6.35	0.25"	9.53	0.375"	1.57	0.062"	#17	50'
BN2560NF0635-1110	6.35	0.25"	11.1	0.437"	2.36	0.093"	#24	50'
BN2560NF0635-1270	6.35	0.25"	12.7	0.5"	3.18	0.125"	#26	50'
BN2560NF0792-1270	7.92	0.312"	12.7	0.5"	2.36	0.093"	#35	50'
BN2560NF0953-1427	9.53	0.375"	14.27	0.562"	2.36	0.093"	#36	50'
BN2560NF0953-1588	9.53	0.375"	15.88	0.625"	3.18	0.125"	#73	50'
BN2560NF0953-1905	9.53	0.375"	19.05	0.75"	1.57	0.062"	---	50'
BN2560NF1270-1905	12.7	0.5"	19.05	0.75"	3.18	0.125"	#82	50'
BN2560NF1270-2223	12.7	0.5"	22.23	0.875"	4.75	0.187"	#88	50'
BN2560NF1588-2223	15.88	0.625"	22.23	0.875	3.18	0.125"	---	50'
BN2560NF1588-2540	15.88	0.625"	25.4	1.0"	4.75	0.187"	#89	50'

Get Started

Request a configuration quote

Tell us your batch volume and application — we’ll route this to the applications engineer who scopes TFF systems, not a general sales queue.

Silibraid US2530
silicone braided hose

Peroxide-cured silicone with polyester braid reinforcement for high-pressure sterile transfer, -90°C to +220°C, 1/4in to 4in.

US2560 Silicone Pump Tubings

US2560 Silicone Pump Tubing’s

SiliPure US2560 Biopharma Tubing is a high-performance, biopharmaceutical-grade tubing made from platinum-cured silicone. Engineered to meet the stringent requirements of the biopharma industry, it offers excellent resistance to repeated autoclaving and minimizes the adhesion of blood products and other sanitary fluids. Available in sizes starting from 1/16" ID and above, SiliPure US2560 features laser-marked part numbers and lot codes to ensure complete product traceability.

Request a Quote

Two Hardness Options – 50 or 65 Shore A.
Ultra-Pure Silicone – Biopharma-grade for high purity and reliability.
Full Traceability – Laser-marked with part numbers and lot codes.
Smooth Inner Surface – Improves fluid flow and prevents particle buildup.
Wide Temperature Range – From -80°F (-62°C) to 500°F (260°C).
Tested for Safety – Extractables & leachables study done for compatibility.
Validation Support – Guide available for regulatory needs.
Bacteria Resistant – Sterilizable and non-reactive to body tissues.
No Plasticizers – Soft, flexible, and contamination-free.
Cleanroom Made – Class 10,000 environment for maximum cleanliness.
Precision Dimensions – Laser-checked for consistent sizing.
Biocompatible – Meets USP Class VI & ISO 10993 standards.
Color-Coded Option – Easy identification during use.
Batch Traceability – Permanent laser etching for every lot.

Sterile Fill and Transfers
Drug Delivery
Media Processing
Cell Harvest
Upstream and Downstream Biopharma Applications
High Purity Water Transfer
Buffer and Media Preparation
Purification Operations
Diagnostics Products

COA
USP Class VI
FDA CFR Title 21-177.2600
Conforms to ISO 10993-1
BSE/TSE (free of animal derived material)
REACH, 3-A* Compliant
RoHS Compliances, Free of Phthalate/ Bisphenol/Volatile Plasticizer

Product Number	ID		OD		Wall thickness		PUMP SIZE	STANDARD LENGTH feet (')
	mm	Inch(")	mm	Inch(")	mm	Inch(")
BN2560NF1905-2858	19.05	0.75"	28.58	1.125"	4.75	0.187"	#191	25'
BN2560NF1905-3175	19.05	0.75"	31.75	1.25"	6.35	0.25"	#90	25'
BN2560NF2540-3493	25.4	1.0"	34.93	1.375"	4.75	0.187"	#92	25'
BN2560NF0157-0475	1.57	0.062"	4.75	0.187"	1.57	0.062"	#14	50'
BN2560NF0157-0635	1.57	0.062"	6.35	0.25"	0.79	0.031"	#119	50'
BN2560NF0318-0635	3.18	0.125"	6.35	0.25"	1.57	0.062"	#16	50'
BN2560NF0318-0792	3.18	0.125"	7.92	0.312"	2.36	0.093"	#03, #25	50'
BN2560NF0475-0335	4.75	0.187"	3.35	0.132"	1.57	0.062"	#25	50'
BN2560NF0475-0953	4.75	0.187"	9.53	0.375"	2.36	0.093"	#15	50'
BN2560NF0475-1110	4.75	0.187"	11.1	0.437"	3.18	0.125"	---	50'
BN2560NF0635-0953	6.35	0.25"	9.53	0.375"	1.57	0.062"	#17	50'
BN2560NF0635-1110	6.35	0.25"	11.1	0.437"	2.36	0.093"	#24	50'
BN2560NF0635-1270	6.35	0.25"	12.7	0.5"	3.18	0.125"	#26	50'
BN2560NF0792-1270	7.92	0.312"	12.7	0.5"	2.36	0.093"	#35	50'
BN2560NF0953-1427	9.53	0.375"	14.27	0.562"	2.36	0.093"	#36	50'
BN2560NF0953-1588	9.53	0.375"	15.88	0.625"	3.18	0.125"	#73	50'
BN2560NF0953-1905	9.53	0.375"	19.05	0.75"	1.57	0.062"	---	50'
BN2560NF1270-1905	12.7	0.5"	19.05	0.75"	3.18	0.125"	#82	50'
BN2560NF1270-2223	12.7	0.5"	22.23	0.875"	4.75	0.187"	#88	50'
BN2560NF1588-2223	15.88	0.625"	22.23	0.875	3.18	0.125"	---	50'
BN2560NF1588-2540	15.88	0.625"	25.4	1.0"	4.75	0.187"	#89	50'
